微型时钟晶体的替代品KXO-V93

2024-01-02 15:23:33

历史2

An alternative to miniature clock GEYER crystals

For several years, GEYER Crystal Oscillator has successfully introduced the KXO-V93T miniature oscillator.
With a small size of just 1.6 x 1.2 mm and a height of just 0.6 mm, this SMD oscillator in the frequency range 1-80 MHz is particularly resistant to shock and vibration and has low power consumption.
The market is increasingly looking for an alternative clock crystal (32.768 kHz) that is not only superior in design, but most importantly superior to traditional clock crystals in terms of technical parameters.
Our answer is a 32.768kHz oscillator with the KXO-V93T proven design with low frequency tolerance, low jitter values, three-state functionality and low power consumption over an extended -40° +85°C temperature range.
The oscillator solves the stability problem of traditional clock crystals over the temperature and voltage range, and can be used in all industries requiring this frequency, such as industrial automation, medical devices, Internet of Things, M2M, wireless sensors, security technology, and more, in addition to the conventional applications of oscillating crystals.
The GEYER Electronic KXO-V93T 32.768kHz quartz crystal oscillator is a future-oriented component that meets the most stringent market technical requirements: frequency tolerance, precipitation time, current consumption.
微型时钟晶体的替代品
近年来，GEYER晶振已成功推出了 KXO-V93T 型微型振荡器。
这款频率范围为 1 - 80 MHz 的 SMD 振荡器尺寸小，仅为 1.6 x 1.2 mm，高度仅为 0.6 mm，特别耐冲击和振动，功耗低。
市场正在越来越多地寻找一种替代时钟晶体（32.768 kHz）的产品，这种产品不仅在设计上更胜一筹，最重要的是在技术参数上也优于传统的时钟晶体。
我们的答案是采用 KXO-V93T 成熟设计的 32.768kHz 振荡器，在扩展的 -40° +85°C 温度范围内具有低频率容差、低抖动值、三态功能和低功耗。
该振荡器解决了传统时钟晶体振荡器在温度和电压范围内的稳定性问题，除了振荡晶体的常规应用外，还可用于所有需要该频率的行业，如工业自动化、医疗设备、物联网、M2M、无线传感器、安全技术等。

GEYER Electronic KXO-V93T 32.768kHz 石英晶体振荡器是一款面向未来的元件，可满足最严格的市场技术要求： 频率公差、沉淀时间、电流消耗。

GEYER原厂编码 生产商品牌 型号 频率 频率容差 频率稳定度 负载 工作温度
12.85536 Geyer晶振 KX-5T 40 MHz ±20ppm ±10ppm 8pF -40°C ~ 85°C
12.84816 Geyer晶振 KX-4 25 MHz ±50ppm ±30ppm 8pF -20°C ~ 70°C
12.88722 Geyer晶振 KX-7T 16 MHz ±25ppm ±10ppm 12pF -20°C ~ 70°C
12.84805 Geyer晶振 KX-4 27.12 MHz ±30ppm ±30ppm 8pF -40°C ~ 85°C
12.86509 Geyer晶振 KX-6 48 MHz ±50ppm ±30ppm 10pF -20°C ~ 70°C
12.89020 Geyer晶振 KX-9A 32 MHz ±10ppm ±30ppm 16pF -20°C ~ 70°C
12.84813 Geyer晶振 KX-4 27.12 MHz ±15ppm ±10ppm 8pF -40°C ~ 85°C
12.60233 Geyer晶振 KX-7T 25 MHz ±20ppm ±20ppm 12pF -40°C ~ 85°C
12.85515 Geyer晶振 KX-5 27 MHz ±50ppm ±30ppm 8pF -20°C ~ 70°C
12.86544 Geyer晶振 KX-7E 24 MHz ±120ppm ±30ppm 10pF -40°C ~ 105°C
12.85547 Geyer晶振 KX-5T 26 MHz ±20ppm ±10ppm 8pF -40°C ~ 85°C
12.89190 Geyer晶振 KX-9AT 8 MHz ±30ppm ±100ppm 16pF -40°C ~ 85°C
12.85562 Geyer晶振 KX-5T 50 MHz ±50ppm ±30ppm 8pF -40°C ~ 85°C
12.60208 Geyer晶振 KX-7T 26 MHz ±10ppm ±20ppm 8pF -40°C ~ 85°C
12.86531 Geyer晶振 KX-6T 16 MHz ±100ppm ±30ppm 10pF -40°C ~ 85°C
12.88664 Geyer晶振 KX-7 14.31818 MHz ±50ppm ±30ppm 12pF -20°C ~ 70°C
12.89495 Geyer晶振 KX-9BH 8 MHz ±50ppm ±50ppm 16pF -20°C ~ 70°C
12.89103 Geyer晶振 KX-9AE 10 MHz ±50ppm ±30ppm 16pF -40°C ~ 105°C
12.88700 Geyer晶振 KX-7 30 MHz ±50ppm ±30ppm 12pF -20°C ~ 70°C
12.89131 Geyer晶振 KX-9AT 48 MHz ±50ppm ±30ppm 16pF -40°C ~ 85°C
12.86512 Geyer晶振 KX-6 20 MHz ±50ppm ±30ppm 10pF -20°C ~ 70°C
12.89126 Geyer晶振 KX-9A 13.56 MHz ±120ppm ±30ppm 16pF -40°C ~ 105°C
12.86550 Geyer晶振 KX-6E 16 MHz ±150ppm ±30ppm 10pF -40°C ~ 105°C
12.86526 Geyer晶振 KX-6T 26 MHz ±20ppm ±10ppm 10pF -40°C ~ 85°C
12.60090 Geyer晶振 KX-7T 24 MHz ±20ppm ±20ppm 12pF -40°C ~ 85°C
12.88701 Geyer晶振 KX-7T 40 MHz ±100ppm ±30ppm 12pF -40°C ~ 85°C
12.88493 Geyer晶振 KX-7T 33.33333 MHz ±100ppm ±30ppm 12pF -40°C ~ 85°C
12.85521 Geyer晶振 KX-5T 26 MHz ±20ppm ±10ppm 10pF -40°C ~ 85°C
12.89078 Geyer晶振 KX-9AT 27 MHz ±150ppm ±30ppm 16pF -40°C ~ 85°C
12.86517 Geyer晶振 KX-6 24 MHz ±50ppm ±30ppm 10pF -20°C ~ 70°C
12.84812 Geyer晶振 KX-4 25 MHz ±50ppm ±30ppm 8pF -40°C ~ 85°C
12.88508 Geyer晶振 KX-7T 24 MHz ±50ppm ±20ppm 12pF -40°C ~ 85°C
12.88711 Geyer晶振 KX-7T 25 MHz ±30ppm ±30ppm 12pF -40°C ~ 85°C
12.85519 Geyer晶振 KX-5T 20 MHz ±50ppm ±20ppm 8pF -40°C ~ 85°C
12.89027 Geyer晶振 KX-9A 25 MHz ±30ppm ±30ppm 16pF -20°C ~ 70°C
12.85539 Geyer晶振 KX-5T 48 MHz ±20ppm ±10ppm 12pF -40°C ~ 85°C
12.88721 Geyer晶振 KX-7T 16 MHz ±30ppm ±30ppm 12pF -20°C ~ 70°C
12.88667 Geyer晶振 KX-7 25 MHz ±50ppm ±30ppm 12pF -20°C ~ 70°C
12.85517 Geyer晶振 KX-5T 54 MHz ±100ppm ±30ppm 8pF -40°C ~ 85°C
12.89017 Geyer晶振 KX-9A 13.56 MHz ±50ppm ±30ppm 16pF -20°C ~ 70°C
12.89082 Geyer晶振 KX-9AT 26 MHz ±50ppm ±30ppm 16pF -40°C ~ 85°C
12.60075 Geyer晶振 KX-7 30 MHz ±50ppm ±30ppm 8pF -40°C ~ 125°C
12.89155 Geyer晶振 KX-9AT 32 MHz ±30ppm ±30ppm 16pF -40°C ~ 85°C
12.88522 Geyer晶振 KX-7T 11.0592 MHz ±50ppm ±30ppm 12pF -20°C ~ 70°C
12.88752 Geyer晶振 KX-7 10 MHz ±50ppm ±30ppm 12pF -20°C ~ 70°C
12.85569 Geyer晶振 KX-5T 27.12 MHz ±15ppm ±10ppm 8pF -40°C ~ 85°C
12.88565 Geyer晶振 KX-7E 8 MHz ±50ppm ±30ppm 12pF -20°C ~ 70°C
12.85538 Geyer晶振 KX-5T 24.576 MHz ±100ppm ±30ppm 8pF -40°C ~ 85°C
12.86533 Geyer晶振 KX-6T 26 MHz ±100ppm ±30ppm 10pF -40°C ~ 85°C
12.89209 Geyer晶振 KX-9AE 16 MHz ±50ppm ±30ppm 20pF -40°C ~ 105°C
12.86520 Geyer晶振 KX-6 27 MHz ±50ppm ±30ppm 10pF -20°C ~ 70°C
12.86574 Geyer晶振 KX-6F 27 MHz ±150ppm ±30ppm 8pF -40°C ~ 125°C
12.85541 Geyer晶振 KX-5 30 MHz ±30ppm ±30ppm 8pF -20°C ~ 70°C
12.84818 Geyer晶振 KX-4 24 MHz ±50ppm ±30ppm 8pF -20°C ~ 70°C
12.86527 Geyer晶振 KX-6T 20 MHz ±15ppm ±10ppm 10pF -40°C ~ 85°C
12.85534 Geyer晶振 KX-5T 27 MHz ±50ppm ±30ppm 8pF -40°C ~ 85°C
12.86505 Geyer晶振 KX-6 26 MHz ±50ppm ±30ppm 10pF -20°C ~ 70°C
12.60024 Geyer晶振 KX-7E 27 MHz ±100ppm ±30ppm 12pF -40°C ~ 105°C
12.84803 Geyer晶振 KX-4 26 MHz ±20ppm ±10ppm 8pF -40°C ~ 85°C
12.85518 Geyer晶振 KX-5E 20 MHz ±50ppm ±30ppm 8pF -40°C ~ 105°C
12.88730 Geyer晶振 KX-7T 26 MHz ±50ppm ±30ppm 12pF -40°C ~ 85°C
12.86556 Geyer晶振 KX-6T 40 MHz ±20ppm ±10ppm 8pF -40°C ~ 85°C
12.88643 Geyer晶振 KX-7T 14.31818 MHz ±50ppm ±30ppm 12pF -40°C ~ 85°C
12.86511 Geyer晶振 KX-6 18.432 MHz ±50ppm ±30ppm 10pF -20°C ~ 70°C
12.88523 Geyer晶振 KX-7F 40 MHz ±50ppm ±30ppm 12pF -40°C ~ 125°C
12.89288 Geyer晶振 KX-9AT 24.576 MHz ±30ppm ±20ppm 20pF -40°C ~ 85°C
12.86536 Geyer晶振 KX-6 14.31818 MHz ±50ppm ±30ppm 10pF -20°C ~ 70°C
12.89029 Geyer晶振 KX-9A 27 MHz ±50ppm ±30ppm 16pF -20°C ~ 70°C
12.88799 Geyer晶振 KX-7 12 MHz ±30ppm ±30ppm 10pF -20°C ~ 70°C
12.84810 Geyer晶振 KX-4 48 MHz ±50ppm ±30ppm 8pF -40°C ~ 85°C
12.84814 Geyer晶振 KX-4 32 MHz ±15ppm ±10ppm 8pF -40°C ~ 85°C
12.88756 Geyer晶振 KX-7E 26 MHz ±50ppm ±10ppm 12pF -40°C ~ 105°C
12.85560 Geyer晶振 KX-5T 16 MHz ±30ppm ±30ppm 8pF -40°C ~ 85°C
12.86561 Geyer晶振 KX-6T 40 MHz ±20ppm ±10ppm 10pF -40°C ~ 85°C
12.88770 Geyer晶振 KX-7T 30 MHz ±10ppm ±10ppm 12pF -25°C ~ 80°C
12.86564 Geyer晶振 KX-6T 14.31818 MHz ±100ppm ±30ppm 10pF -40°C ~ 85°C
