美国FOX晶振,领先全球的北斗卫星定位模块晶振,FC1BACBEI38.4晶振

美国FOX晶振,领先全球的北斗卫星定位模块晶振,FC1BACBEI38.4晶振美国FOX晶振,领先全球的北斗卫星定位模块晶振,FC1BACBEI38.4晶振

产品简介

美国FOX晶振,领先全球的北斗卫星定位模块晶振,FC1BACBEI38.4晶振,美国FOX晶振公司，超小型晶振是高可靠的环保性能,严格的频率分选,编带盘装,可应用于高速自动贴片机焊接,产品本身设计合理,成本和性能良好,产品被广泛应用于平板电脑,MP5,数码相机,USB接口最佳选择,包含RoHS指令豁免的密封玻璃中的铅.2016尺寸贴片晶振系列，在生产时就得对每项生产工艺严格把关，对每项参数做到标准检测，有一项不完善都会使晶片的边缘效应不能去除，而晶片的谐振电阻过大，用在电路中Q值过小，从而电路不能振动或振动不稳定。高品质晶振，石英晶体谐振器，四脚晶振，SMD晶振，贴片晶振,石英晶振,高可靠晶振，环保晶振，小体积晶振，6G通讯设备晶振，室外6G基站晶振，2016晶振，无人机遥控晶振。

产品详情

1

美国FOX晶振,领先全球的北斗卫星定位模块晶振,FC1BACBEI38.4晶振,美国FOX晶振公司，超小型晶振是高可靠的环保性能,严格的频率分选,编带盘装,可应用于高速自动贴片机焊接,产品本身设计合理,成本和性能良好,产品被广泛应用于平板电脑,MP5,数码相机,USB接口最佳选择,包含RoHS指令豁免的密封玻璃中的铅.2016尺寸贴片晶振系列，在生产时就得对每项生产工艺严格把关，对每项参数做到标准检测，有一项不完善都会使晶片的边缘效应不能去除，而晶片的谐振电阻过大，用在电路中Q值过小，从而电路不能振动或振动不稳定。高品质晶振，石英晶体谐振器，四脚晶振，SMD晶振，贴片晶振,石英晶振,高可靠晶振，环保晶振，小体积晶振，6G通讯设备晶振，室外6G基站晶振，2016晶振，无人机遥控晶振。

美国FOX晶振,领先全球的北斗卫星定位模块晶振,FC1BACBEI38.4晶振

参数 MAX (unless otherwise noted)
频率范围 20.000 ~ 50.000 MHz
频率容差 ±10 PPM ~ ±50 PPM(See options on page 2)
频率稳定度 ±20 PPM ~ ±100 PPM(See options below)
工作温度范围 -40ºC ~ +125ºC (see options below)
储存温度范围 -55ºC ~ +150ºC
分流电容 3pF
负载电容 7pF~Series(See options on page 2)
驱动电平 100µW
老化 ±5 PPM
最大焊接温度/时间 260ºC / 10 Seconds
湿度敏感性水平 1
终止完成 Au
密封方式 Seam Seal
无铅 Yes
符合RoHS No Exemptions

3

美国FOX晶振,领先全球的北斗卫星定位模块晶振,FC1BACBEI38.4晶振

C1BA

C1BA-1

FOX原厂编码 生产商 型号 频率 频率稳定度 频率容差 负载电容
FC4SDCBMF10.0-T1 Fox晶振 HC49SDLF 10 MHz ±50ppm ±30ppm 20pF
FC4SDCBMF8.0-T1 Fox晶振 HC49SDLF 8 MHz ±50ppm ±30ppm 20pF
FC4SDCBMF3.6864-T1 Fox晶振 HC49SDLF 3.6864 MHz ±50ppm ±30ppm 20pF
FKFSREIHM0.032768-T3 Fox晶振 FSRLF 32.768 kHz - ±20ppm 12.5pF
FC4STCBMF20.0 Fox晶振 HC49SLF 20 MHz ±50ppm ±30ppm 20pF
FK135EIHM0.032768-T3 Fox晶振 K135 32.768 kHz - ±20ppm 12.5pF
FC5BQCCMC12.0-T1 Fox晶振 C5BQ 12 MHz ±30ppm ±30ppm 20pF
FC5BQCCMM25.0-T1 Fox晶振 C5BQ 25 MHz ±30ppm ±30ppm 20pF
FC5BQCCMM12.0-T1 Fox晶振 C5BQ 12 MHz ±50ppm ±30ppm 20pF
FC7BSCCMM8.0-T1 Fox晶振 C7BS 8 MHz ±30ppm ±30ppm 20pF
FC7BSCCMM7.3728-T1 Fox晶振 C7BS 7.3728 MHz ±30ppm ±30ppm 20pF
FKFSXEIHM0.032768-T3 Fox晶振 FSXLF 32.768 kHz - ±20ppm 12.5pF
FKFSREIBM0.032768-T3 Fox晶振 FSRLF 32.768 kHz - ±20ppm 6pF
FC8AQCCMC3.6864-T1 Fox晶振 FC8AQ 3.6864 MHz ±30ppm ±30ppm 20pF
FC8AQCCMC4.0-T1 Fox晶振 FC8AQ 4 MHz ±30ppm ±30ppm 20pF
FC4SDCBMF11.0592-T1 Fox晶振 HC49SDLF 11.0592 MHz ±50ppm ±30ppm 20pF
FC4SDCBMF25.0-T1 Fox晶振 HC49SDLF 25 MHz ±50ppm ±30ppm 20pF
FC4SDCBMF16.0-T1 Fox晶振 HC49SDLF 16 MHz ±50ppm ±30ppm 20pF
FC4SDCBMF12.0-T1 Fox晶振 HC49SDLF 12 MHz ±50ppm ±30ppm 20pF
FC4SDCBMF24.0-T1 Fox晶振 HC49SDLF 24 MHz ±50ppm ±30ppm 20pF
FC4SDCBMM25.0-T1 Fox晶振 HC49SDLF 25 MHz ±50ppm ±30ppm 20pF
FC4SDCBMF14.7456-T1 Fox晶振 HC49SDLF 14.7456 MHz ±50ppm ±30ppm 20pF
FC4SDCBMM8.0-T1 Fox晶振 HC49SDLF 8 MHz ±50ppm ±30ppm 20pF
FC4SDCBMF7.3728-T1 Fox晶振 HC49SDLF 7.3728 MHz ±50ppm ±30ppm 20pF
FC4SDCBMF6.0-T1 Fox晶振 HC49SDLF 6 MHz ±50ppm ±30ppm 20pF
FC4SDCBMF4.0-T1 Fox晶振 HC49SDLF 4 MHz ±50ppm ±30ppm 20pF
FC3BQBBME12.0-T3 Fox晶振 FQ3225B 12 MHz ±50ppm ±50ppm 20pF
FC3BQBBMM25.0-T3 Fox晶振 FC3BQ 25 MHz ±50ppm ±50ppm 20pF
FKT38EIHD0.032768 Fox晶振 NC38LF 32.768 kHz - ±20ppm 12.5pF
FC4STCBMF10.0 Fox晶振 HC49SLF 10 MHz ±50ppm ±30ppm 20pF
FC4STCBMF25.0 Fox晶振 HC49SLF 25 MHz ±50ppm ±30ppm 20pF
FC4STCBMF16.0 Fox晶振 HC49SLF 16 MHz ±50ppm ±30ppm 20pF
FC4STCBMF12.0 Fox晶振 HC49SLF 12 MHz ±50ppm ±30ppm 20pF
FC4STCBMF11.0592 Fox晶振 HC49SLF 11.0592 MHz ±50ppm ±30ppm 20pF
FC4STCBMF8.0 Fox晶振 HC49SLF 8 MHz ±50ppm ±30ppm 20pF
FC4STCBMF7.3728 Fox晶振 HC49SLF 7.3728 MHz ±50ppm ±30ppm 20pF
FC4STCBLF3.579545 Fox晶振 HC49SLF 3.579545 MHz ±50ppm ±30ppm 18pF
FC4STCBMF4.0 Fox晶振 HC49SLF 4 MHz ±50ppm ±30ppm 20pF
FC4STCBMF3.6864 Fox晶振 HC49SLF 3.6864 MHz ±50ppm ±30ppm 20pF
FKT26EIHD0.032768 Fox晶振 NC26LF 32.768 kHz - ±20ppm 12.5pF
FKT38EIHQ0.032768 Fox晶振 NC38LF 32.768 kHz - ±20ppm 12.5pF
FC5BQCCMC25.0-T1 Fox晶振 C5BQ 25 MHz ±30ppm ±30ppm 20pF
FC5BQCCMC24.0-T1 Fox晶振 C5BQ 24 MHz ±30ppm ±30ppm 20pF
FC5BQCCMC20.0-T1 Fox晶振 C5BQ 20 MHz ±30ppm ±30ppm 20pF
FC5BQCCMC16.0-T1 Fox晶振 C5BQ 16 MHz ±30ppm ±30ppm 20pF
FC7BSCCMC8.0-T1 Fox晶振 C7BS 8 MHz ±30ppm ±30ppm 20pF
FC7BSCCMM6.0-T1 Fox晶振 C7BS 6 MHz ±30ppm ±30ppm 20pF
FC7BSCCMC7.3728-T1 Fox晶振 C7BS 7.3728 MHz ±30ppm ±30ppm 20pF
FC8AQCCMC6.0-T1 Fox晶振 FC8AQ 6 MHz ±30ppm ±30ppm 20pF
FC4SDCBMF12.288-T1 Fox晶振 HC49SDLF 12.288 MHz ±50ppm ±30ppm 20pF
FC4SDCBMM16.0-T1 Fox晶振 HC49SDLF 16 MHz ±50ppm ±30ppm 20pF
FC4SDCBMF18.432-T1 Fox晶振 HC49SDLF 18.432 MHz ±50ppm ±30ppm 20pF
FC4SDCBLF3.579545-T1 Fox晶振 HC49SDLF 3.579545 MHz ±50ppm ±30ppm 18pF
FC4SDCBMM4.0-T1 Fox晶振 HC49SDLF 4 MHz ±50ppm ±30ppm 20pF
FC2BSBBMM16.0-T3 Fox晶振 FX252B 16 MHz ±50ppm ±50ppm 20pF
FC4STCBMF18.432 Fox晶振 HC49SLF 18.432 MHz ±50ppm ±30ppm 20pF
FC4STCBMF14.7456 Fox晶振 HC49SLF 14.7456 MHz ±50ppm ±30ppm 20pF
FKT26EIHQ0.032768 Fox晶振 NC26LF 32.768 kHz - ±20ppm 12.5pF
FC3BACALI16.0-T3 Fox晶振 C3BA 16 MHz ±100ppm ±30ppm 18pF
FC3BACBDI16.0-T3 Fox晶振 C3BA 16 MHz ±50ppm ±30ppm 8pF
FC7BSCCMC6.0-T1 Fox晶振 C7BS 6 MHz ±30ppm ±30ppm 20pF
FK122EIHM0.032768-T3 Fox晶振 FK122 32.768 kHz - ±20ppm 12.5pF
FK135EIWM0.032768-T3 Fox晶振 K135 32.768 kHz - ±20ppm 9pF
FC7ASBBMD10.0-T1 Fox晶振 C7AS 10 MHz ±50ppm ±50ppm 20pF
FC4SDCBMM20.0-T1 Fox晶振 HC49SDLF 20 MHz ±50ppm ±30ppm 20pF
FC4STCBMF9.8304 Fox晶振 C4ST 9.8304 MHz ±50ppm ±30ppm 20pF
FK122EIWM0.032768-T3 Fox晶振 FK122 32.768 kHz - ±20ppm 9pF
FK122HIHM0.032768-T3 Fox晶振 FK122 32.768 kHz - ±10ppm 12.5pF
FK161EIWM0.032768-T5 Fox晶振 FK161 32.768 kHz - ±20ppm 9pF
FC3BQBBMM24.0-T3 Fox晶振 FC3BQ 24 MHz ±50ppm ±50ppm 20pF
FC3BQBBMM12.0-T3 Fox晶振 FC3BQ 12 MHz ±50ppm ±50ppm 20pF

6
