微型时钟晶体的替代品KXO-V93

来源：精工富士查看手机网址

扫一扫!

扫一扫!

浏览：- 发布日期：2024-01-02 15:23:33【大中小】

分享到：

An alternative to miniature clock GEYER crystals

For several years, GEYER Crystal Oscillator has successfully introduced the KXO-V93T miniature oscillator.
With a small size of just 1.6 x 1.2 mm and a height of just 0.6 mm, this SMD oscillator in the frequency range 1-80 MHz is particularly resistant to shock and vibration and has low power consumption.
The market is increasingly looking for an alternative clock crystal (32.768 kHz) that is not only superior in design, but most importantly superior to traditional clock crystals in terms of technical parameters.
Our answer is a 32.768kHz oscillator with the KXO-V93T proven design with low frequency tolerance, low jitter values, three-state functionality and low power consumption over an extended -40° +85°C temperature range.
The oscillator solves the stability problem of traditional clock crystals over the temperature and voltage range, and can be used in all industries requiring this frequency, such as industrial automation, medical devices, Internet of Things, M2M, wireless sensors, security technology, and more, in addition to the conventional applications of oscillating crystals.
The GEYER Electronic KXO-V93T 32.768kHz quartz crystal oscillator is a future-oriented component that meets the most stringent market technical requirements: frequency tolerance, precipitation time, current consumption.
微型时钟晶体的替代品
近年来，GEYER晶振已成功推出了 KXO-V93T 型微型振荡器。
这款频率范围为 1 - 80 MHz 的 SMD 振荡器尺寸小，仅为 1.6 x 1.2 mm，高度仅为 0.6 mm，特别耐冲击和振动，功耗低。
市场正在越来越多地寻找一种替代时钟晶体（32.768 kHz）的产品，这种产品不仅在设计上更胜一筹，最重要的是在技术参数上也优于传统的时钟晶体。
我们的答案是采用 KXO-V93T 成熟设计的 32.768kHz 振荡器，在扩展的 -40° +85°C 温度范围内具有低频率容差、低抖动值、三态功能和低功耗。
该振荡器解决了传统时钟晶体振荡器在温度和电压范围内的稳定性问题，除了振荡晶体的常规应用外，还可用于所有需要该频率的行业，如工业自动化、医疗设备、物联网、M2M、无线传感器、安全技术等。

GEYER Electronic KXO-V93T 32.768kHz 石英晶体振荡器是一款面向未来的元件，可满足最严格的市场技术要求：频率公差、沉淀时间、电流消耗。

GEYER原厂编码	生产商品牌	型号	频率	频率容差	频率稳定度	负载	工作温度
12.85536	Geyer晶振	KX-5T	40 MHz	±20ppm	±10ppm	8pF	-40°C ~ 85°C
12.84816	Geyer晶振	KX-4	25 MHz	±50ppm	±30ppm	8pF	-20°C ~ 70°C
12.88722	Geyer晶振	KX-7T	16 MHz	±25ppm	±10ppm	12pF	-20°C ~ 70°C
12.84805	Geyer晶振	KX-4	27.12 MHz	±30ppm	±30ppm	8pF	-40°C ~ 85°C
12.86509	Geyer晶振	KX-6	48 MHz	±50ppm	±30ppm	10pF	-20°C ~ 70°C
12.89020	Geyer晶振	KX-9A	32 MHz	±10ppm	±30ppm	16pF	-20°C ~ 70°C
12.84813	Geyer晶振	KX-4	27.12 MHz	±15ppm	±10ppm	8pF	-40°C ~ 85°C
12.60233	Geyer晶振	KX-7T	25 MHz	±20ppm	±20ppm	12pF	-40°C ~ 85°C
12.85515	Geyer晶振	KX-5	27 MHz	±50ppm	±30ppm	8pF	-20°C ~ 70°C
12.86544	Geyer晶振	KX-7E	24 MHz	±120ppm	±30ppm	10pF	-40°C ~ 105°C
12.85547	Geyer晶振	KX-5T	26 MHz	±20ppm	±10ppm	8pF	-40°C ~ 85°C
12.89190	Geyer晶振	KX-9AT	8 MHz	±30ppm	±100ppm	16pF	-40°C ~ 85°C
12.85562	Geyer晶振	KX-5T	50 MHz	±50ppm	±30ppm	8pF	-40°C ~ 85°C
12.60208	Geyer晶振	KX-7T	26 MHz	±10ppm	±20ppm	8pF	-40°C ~ 85°C
12.86531	Geyer晶振	KX-6T	16 MHz	±100ppm	±30ppm	10pF	-40°C ~ 85°C
12.88664	Geyer晶振	KX-7	14.31818 MHz	±50ppm	±30ppm	12pF	-20°C ~ 70°C
12.89495	Geyer晶振	KX-9BH	8 MHz	±50ppm	±50ppm	16pF	-20°C ~ 70°C
12.89103	Geyer晶振	KX-9AE	10 MHz	±50ppm	±30ppm	16pF	-40°C ~ 105°C
12.88700	Geyer晶振	KX-7	30 MHz	±50ppm	±30ppm	12pF	-20°C ~ 70°C
12.89131	Geyer晶振	KX-9AT	48 MHz	±50ppm	±30ppm	16pF	-40°C ~ 85°C
12.86512	Geyer晶振	KX-6	20 MHz	±50ppm	±30ppm	10pF	-20°C ~ 70°C
12.89126	Geyer晶振	KX-9A	13.56 MHz	±120ppm	±30ppm	16pF	-40°C ~ 105°C
12.86550	Geyer晶振	KX-6E	16 MHz	±150ppm	±30ppm	10pF	-40°C ~ 105°C
12.86526	Geyer晶振	KX-6T	26 MHz	±20ppm	±10ppm	10pF	-40°C ~ 85°C
12.60090	Geyer晶振	KX-7T	24 MHz	±20ppm	±20ppm	12pF	-40°C ~ 85°C
12.88701	Geyer晶振	KX-7T	40 MHz	±100ppm	±30ppm	12pF	-40°C ~ 85°C
12.88493	Geyer晶振	KX-7T	33.33333 MHz	±100ppm	±30ppm	12pF	-40°C ~ 85°C
12.85521	Geyer晶振	KX-5T	26 MHz	±20ppm	±10ppm	10pF	-40°C ~ 85°C
12.89078	Geyer晶振	KX-9AT	27 MHz	±150ppm	±30ppm	16pF	-40°C ~ 85°C
12.86517	Geyer晶振	KX-6	24 MHz	±50ppm	±30ppm	10pF	-20°C ~ 70°C
12.84812	Geyer晶振	KX-4	25 MHz	±50ppm	±30ppm	8pF	-40°C ~ 85°C
12.88508	Geyer晶振	KX-7T	24 MHz	±50ppm	±20ppm	12pF	-40°C ~ 85°C
12.88711	Geyer晶振	KX-7T	25 MHz	±30ppm	±30ppm	12pF	-40°C ~ 85°C
12.85519	Geyer晶振	KX-5T	20 MHz	±50ppm	±20ppm	8pF	-40°C ~ 85°C
12.89027	Geyer晶振	KX-9A	25 MHz	±30ppm	±30ppm	16pF	-20°C ~ 70°C
12.85539	Geyer晶振	KX-5T	48 MHz	±20ppm	±10ppm	12pF	-40°C ~ 85°C
12.88721	Geyer晶振	KX-7T	16 MHz	±30ppm	±30ppm	12pF	-20°C ~ 70°C
12.88667	Geyer晶振	KX-7	25 MHz	±50ppm	±30ppm	12pF	-20°C ~ 70°C
12.85517	Geyer晶振	KX-5T	54 MHz	±100ppm	±30ppm	8pF	-40°C ~ 85°C
12.89017	Geyer晶振	KX-9A	13.56 MHz	±50ppm	±30ppm	16pF	-20°C ~ 70°C
12.89082	Geyer晶振	KX-9AT	26 MHz	±50ppm	±30ppm	16pF	-40°C ~ 85°C
12.60075	Geyer晶振	KX-7	30 MHz	±50ppm	±30ppm	8pF	-40°C ~ 125°C
12.89155	Geyer晶振	KX-9AT	32 MHz	±30ppm	±30ppm	16pF	-40°C ~ 85°C
12.88522	Geyer晶振	KX-7T	11.0592 MHz	±50ppm	±30ppm	12pF	-20°C ~ 70°C
12.88752	Geyer晶振	KX-7	10 MHz	±50ppm	±30ppm	12pF	-20°C ~ 70°C
12.85569	Geyer晶振	KX-5T	27.12 MHz	±15ppm	±10ppm	8pF	-40°C ~ 85°C
12.88565	Geyer晶振	KX-7E	8 MHz	±50ppm	±30ppm	12pF	-20°C ~ 70°C
12.85538	Geyer晶振	KX-5T	24.576 MHz	±100ppm	±30ppm	8pF	-40°C ~ 85°C
12.86533	Geyer晶振	KX-6T	26 MHz	±100ppm	±30ppm	10pF	-40°C ~ 85°C
12.89209	Geyer晶振	KX-9AE	16 MHz	±50ppm	±30ppm	20pF	-40°C ~ 105°C
12.86520	Geyer晶振	KX-6	27 MHz	±50ppm	±30ppm	10pF	-20°C ~ 70°C
12.86574	Geyer晶振	KX-6F	27 MHz	±150ppm	±30ppm	8pF	-40°C ~ 125°C
12.85541	Geyer晶振	KX-5	30 MHz	±30ppm	±30ppm	8pF	-20°C ~ 70°C
12.84818	Geyer晶振	KX-4	24 MHz	±50ppm	±30ppm	8pF	-20°C ~ 70°C
12.86527	Geyer晶振	KX-6T	20 MHz	±15ppm	±10ppm	10pF	-40°C ~ 85°C
12.85534	Geyer晶振	KX-5T	27 MHz	±50ppm	±30ppm	8pF	-40°C ~ 85°C
12.86505	Geyer晶振	KX-6	26 MHz	±50ppm	±30ppm	10pF	-20°C ~ 70°C
12.60024	Geyer晶振	KX-7E	27 MHz	±100ppm	±30ppm	12pF	-40°C ~ 105°C
12.84803	Geyer晶振	KX-4	26 MHz	±20ppm	±10ppm	8pF	-40°C ~ 85°C
12.85518	Geyer晶振	KX-5E	20 MHz	±50ppm	±30ppm	8pF	-40°C ~ 105°C
12.88730	Geyer晶振	KX-7T	26 MHz	±50ppm	±30ppm	12pF	-40°C ~ 85°C
12.86556	Geyer晶振	KX-6T	40 MHz	±20ppm	±10ppm	8pF	-40°C ~ 85°C
12.88643	Geyer晶振	KX-7T	14.31818 MHz	±50ppm	±30ppm	12pF	-40°C ~ 85°C
12.86511	Geyer晶振	KX-6	18.432 MHz	±50ppm	±30ppm	10pF	-20°C ~ 70°C
12.88523	Geyer晶振	KX-7F	40 MHz	±50ppm	±30ppm	12pF	-40°C ~ 125°C
12.89288	Geyer晶振	KX-9AT	24.576 MHz	±30ppm	±20ppm	20pF	-40°C ~ 85°C
12.86536	Geyer晶振	KX-6	14.31818 MHz	±50ppm	±30ppm	10pF	-20°C ~ 70°C
12.89029	Geyer晶振	KX-9A	27 MHz	±50ppm	±30ppm	16pF	-20°C ~ 70°C
12.88799	Geyer晶振	KX-7	12 MHz	±30ppm	±30ppm	10pF	-20°C ~ 70°C
12.84810	Geyer晶振	KX-4	48 MHz	±50ppm	±30ppm	8pF	-40°C ~ 85°C
12.84814	Geyer晶振	KX-4	32 MHz	±15ppm	±10ppm	8pF	-40°C ~ 85°C
12.88756	Geyer晶振	KX-7E	26 MHz	±50ppm	±10ppm	12pF	-40°C ~ 105°C
12.85560	Geyer晶振	KX-5T	16 MHz	±30ppm	±30ppm	8pF	-40°C ~ 85°C
12.86561	Geyer晶振	KX-6T	40 MHz	±20ppm	±10ppm	10pF	-40°C ~ 85°C
12.88770	Geyer晶振	KX-7T	30 MHz	±10ppm	±10ppm	12pF	-25°C ~ 80°C
12.86564	Geyer晶振	KX-6T	14.31818 MHz	±100ppm	±30ppm	10pF	-40°C ~ 85°C
