美国FOX晶振,领先全球的北斗卫星定位模块晶振,FC1BACBEI38.4晶振
频率：38.4MHZ
尺寸：2016mm
美国FOX晶振,领先全球的北斗卫星定位模块晶振,FC1BACBEI38.4晶振,美国FOX晶振公司，超小型晶振是高可靠的环保性能,严格的频率分选,编带盘装,可应用于高速自动贴片机焊接,产品本身设计合理,成本和性能良好,产品被广泛应用于平板电脑,MP5,数码相机,USB接口最佳选择,包含RoHS指令豁免的密封玻璃中的铅.2016尺寸贴片晶振系列，在生产时就得对每项生产工艺严格把关，对每项参数做到标准检测，有一项不完善都会使晶片的边缘效应不能去除，而晶片的谐振电阻过大，用在电路中Q值过小，从而电路不能振动或振动不稳定。高品质晶振，石英晶体谐振器，四脚晶振，SMD晶振，贴片晶振,石英晶振,高可靠晶振，环保晶振，小体积晶振，6G通讯设备晶振，室外6G基站晶振，2016晶振，无人机遥控晶振。
美国FOX晶振,领先全球的北斗卫星定位模块晶振,FC1BACBEI38.4晶振
| 参数 | MAX (unless otherwise noted) |
| 频率范围 | 20.000 ~ 50.000 MHz |
| 频率容差 | ±10 PPM ~ ±50 PPM(See options on page 2) |
| 频率稳定度 | ±20 PPM ~ ±100 PPM(See options below) |
| 工作温度范围 | -40ºC ~ +125ºC (see options below) |
| 储存温度范围 | -55ºC ~ +150ºC |
| 分流电容 | 3pF |
| 负载电容 | 7pF~Series(See options on page 2) |
| 驱动电平 | 100µW |
| 老化 | ±5 PPM |
| 最大焊接温度/时间 | 260ºC / 10 Seconds |
| 湿度敏感性水平 | 1 |
| 终止完成 | Au |
| 密封方式 | Seam Seal |
| 无铅 | Yes |
| 符合RoHS | No Exemptions |
美国FOX晶振,领先全球的北斗卫星定位模块晶振,FC1BACBEI38.4晶振
FOX原厂编码
生产商
型号
频率
频率稳定度
频率容差
负载电容
FC4SDCBMF10.0-T1
Fox晶振
HC49SDLF
10 MHz
±50ppm
±30ppm
20pF
FC4SDCBMF8.0-T1
Fox晶振
HC49SDLF
8 MHz
±50ppm
±30ppm
20pF
FC4SDCBMF3.6864-T1
Fox晶振
HC49SDLF
3.6864 MHz
±50ppm
±30ppm
20pF
FKFSREIHM0.032768-T3
Fox晶振
FSRLF
32.768 kHz
-
±20ppm
12.5pF
FC4STCBMF20.0
Fox晶振
HC49SLF
20 MHz
±50ppm
±30ppm
20pF
FK135EIHM0.032768-T3
Fox晶振
K135
32.768 kHz
-
±20ppm
12.5pF
FC5BQCCMC12.0-T1
Fox晶振
C5BQ
12 MHz
±30ppm
±30ppm
20pF
FC5BQCCMM25.0-T1
Fox晶振
C5BQ
25 MHz
±30ppm
±30ppm
20pF
FC5BQCCMM12.0-T1
Fox晶振
C5BQ
12 MHz
±50ppm
±30ppm
20pF
FC7BSCCMM8.0-T1
Fox晶振
C7BS
8 MHz
±30ppm
±30ppm
20pF
FC7BSCCMM7.3728-T1
Fox晶振
C7BS
7.3728 MHz
±30ppm
±30ppm
20pF
FKFSXEIHM0.032768-T3
Fox晶振
FSXLF
32.768 kHz
-
±20ppm
12.5pF
FKFSREIBM0.032768-T3
Fox晶振
FSRLF
32.768 kHz
-
±20ppm
6pF
FC8AQCCMC3.6864-T1
Fox晶振
FC8AQ
3.6864 MHz
±30ppm
±30ppm
20pF
FC8AQCCMC4.0-T1
Fox晶振
FC8AQ
4 MHz
±30ppm
±30ppm
20pF
FC4SDCBMF11.0592-T1
Fox晶振
HC49SDLF
11.0592 MHz
±50ppm
±30ppm
20pF
FC4SDCBMF25.0-T1
Fox晶振
HC49SDLF
25 MHz
±50ppm
±30ppm
20pF
FC4SDCBMF16.0-T1
Fox晶振
HC49SDLF
16 MHz
±50ppm
±30ppm
20pF
FC4SDCBMF12.0-T1
Fox晶振
HC49SDLF
12 MHz
±50ppm
±30ppm
20pF
FC4SDCBMF24.0-T1
Fox晶振
HC49SDLF
24 MHz
±50ppm
±30ppm
20pF
FC4SDCBMM25.0-T1
Fox晶振
HC49SDLF
25 MHz
±50ppm
±30ppm
20pF
FC4SDCBMF14.7456-T1
Fox晶振
HC49SDLF
14.7456 MHz
±50ppm
±30ppm
20pF
FC4SDCBMM8.0-T1
Fox晶振
HC49SDLF
8 MHz
±50ppm
±30ppm
20pF
FC4SDCBMF7.3728-T1
Fox晶振
HC49SDLF
7.3728 MHz
±50ppm
±30ppm
20pF
FC4SDCBMF6.0-T1
Fox晶振
HC49SDLF
6 MHz
±50ppm
±30ppm
20pF
FC4SDCBMF4.0-T1
Fox晶振
HC49SDLF
4 MHz
±50ppm
±30ppm
20pF
FC3BQBBME12.0-T3
Fox晶振
FQ3225B
12 MHz
±50ppm
±50ppm
20pF
FC3BQBBMM25.0-T3
Fox晶振
FC3BQ
25 MHz
±50ppm
±50ppm
20pF
FKT38EIHD0.032768
Fox晶振
NC38LF
32.768 kHz
-
±20ppm
12.5pF
FC4STCBMF10.0
Fox晶振
HC49SLF
10 MHz
±50ppm
±30ppm
20pF
FC4STCBMF25.0
Fox晶振
HC49SLF
25 MHz
±50ppm
±30ppm
20pF
FC4STCBMF16.0
Fox晶振
HC49SLF
16 MHz
±50ppm
±30ppm
20pF
FC4STCBMF12.0
Fox晶振
HC49SLF
12 MHz
±50ppm
±30ppm
20pF
FC4STCBMF11.0592
Fox晶振
HC49SLF
11.0592 MHz
±50ppm
±30ppm
20pF
FC4STCBMF8.0
Fox晶振
HC49SLF
8 MHz
±50ppm
±30ppm
20pF
FC4STCBMF7.3728
Fox晶振
HC49SLF
7.3728 MHz
±50ppm
±30ppm
20pF
FC4STCBLF3.579545
Fox晶振
HC49SLF
3.579545 MHz
±50ppm
±30ppm
18pF
FC4STCBMF4.0
Fox晶振
HC49SLF
4 MHz
±50ppm
±30ppm
20pF
FC4STCBMF3.6864
Fox晶振
HC49SLF
3.6864 MHz
±50ppm
±30ppm
20pF
FKT26EIHD0.032768
Fox晶振
NC26LF
32.768 kHz
-
±20ppm
12.5pF
FKT38EIHQ0.032768
Fox晶振
NC38LF
32.768 kHz
-
±20ppm
12.5pF
FC5BQCCMC25.0-T1
Fox晶振
C5BQ
25 MHz
±30ppm
±30ppm
20pF
FC5BQCCMC24.0-T1
Fox晶振
C5BQ
24 MHz
±30ppm
±30ppm
20pF
FC5BQCCMC20.0-T1
Fox晶振
C5BQ
20 MHz
±30ppm
±30ppm
20pF
FC5BQCCMC16.0-T1
Fox晶振
C5BQ
16 MHz
±30ppm
±30ppm
20pF
FC7BSCCMC8.0-T1
Fox晶振
C7BS
8 MHz
±30ppm
±30ppm
20pF
FC7BSCCMM6.0-T1
Fox晶振
C7BS
6 MHz
±30ppm
±30ppm
20pF
FC7BSCCMC7.3728-T1
Fox晶振
C7BS
7.3728 MHz
±30ppm
±30ppm
20pF
FC8AQCCMC6.0-T1
Fox晶振
FC8AQ
6 MHz
±30ppm
±30ppm
20pF
FC4SDCBMF12.288-T1
Fox晶振
HC49SDLF
12.288 MHz
±50ppm
±30ppm
20pF
FC4SDCBMM16.0-T1
Fox晶振
HC49SDLF
16 MHz
±50ppm
±30ppm
20pF
FC4SDCBMF18.432-T1
Fox晶振
HC49SDLF
18.432 MHz
±50ppm
±30ppm
20pF
FC4SDCBLF3.579545-T1
Fox晶振
HC49SDLF
3.579545 MHz
±50ppm
±30ppm
18pF
FC4SDCBMM4.0-T1
Fox晶振
HC49SDLF
4 MHz
±50ppm
±30ppm
20pF
FC2BSBBMM16.0-T3
Fox晶振
FX252B
16 MHz
±50ppm
±50ppm
20pF
FC4STCBMF18.432
Fox晶振
HC49SLF
18.432 MHz
±50ppm
±30ppm
20pF
FC4STCBMF14.7456
Fox晶振
HC49SLF
14.7456 MHz
±50ppm
±30ppm
20pF
FKT26EIHQ0.032768
Fox晶振
NC26LF
32.768 kHz
-
±20ppm
12.5pF
FC3BACALI16.0-T3
Fox晶振
C3BA
16 MHz
±100ppm
±30ppm
18pF
FC3BACBDI16.0-T3
Fox晶振
C3BA
16 MHz
±50ppm
±30ppm
8pF
FC7BSCCMC6.0-T1
Fox晶振
C7BS
6 MHz
±30ppm
±30ppm
20pF
FK122EIHM0.032768-T3
Fox晶振
FK122
32.768 kHz
-
±20ppm
12.5pF
FK135EIWM0.032768-T3
Fox晶振
K135
32.768 kHz
-
±20ppm
9pF
FC7ASBBMD10.0-T1
Fox晶振
C7AS
10 MHz
±50ppm
±50ppm
20pF
FC4SDCBMM20.0-T1
Fox晶振
HC49SDLF
20 MHz
±50ppm
±30ppm
20pF
FC4STCBMF9.8304
Fox晶振
C4ST
9.8304 MHz
±50ppm
±30ppm
20pF
FK122EIWM0.032768-T3
Fox晶振
FK122
32.768 kHz
-
±20ppm
9pF
FK122HIHM0.032768-T3
Fox晶振
FK122
32.768 kHz
-
±10ppm
12.5pF
FK161EIWM0.032768-T5
Fox晶振
FK161
32.768 kHz
-
±20ppm
9pF
FC3BQBBMM24.0-T3
Fox晶振
FC3BQ
24 MHz
±50ppm
±50ppm
20pF
FC3BQBBMM12.0-T3
Fox晶振
FC3BQ
12 MHz
±50ppm
±50ppm
20pF
