MX555ABB100M000RA-6G模块晶振-LVDS差分晶振
频率：100MHz
尺寸：5.0×3.2mm
MX555ABB100M000RA-6G模块晶振-LVDS差分晶振,Microchip晶振,MX55有源晶振,MX555ABB100M000RA晶振,LVDS差分晶振,5032mm贴片晶振,石英晶体振荡器,欧美进口晶振,频率100MHz,电压3.3V,频率稳定性50ppm,工作温度-40~85°C,低相噪晶振,超低抖动晶振,6G模块晶振,CPRI晶振,10/40/100G以太网晶振,光学通信晶振,光纤通道晶振.
订购热线：0755-27838351
MX555ABB100M000RA-6G模块晶振-LVDS差分晶振,Microchip晶振,MX55有源晶振,MX555ABB100M000RA晶振,LVDS差分晶振,5032mm贴片晶振,石英晶体振荡器,欧美进口晶振,频率100MHz,电压3.3V,频率稳定性50ppm,工作温度-40~85°C,低相噪晶振,超低抖动晶振,6G模块晶振,CPRI晶振,10/40/100G以太网晶振,光学通信晶振,光纤通道晶振.
MX555ABB100M000RA-6G模块晶振-LVDS差分晶振特点：
•频率范围:2.5mhz ~ 850mhz
•符合PCIe Gen 1/2/3/4/5/6 Common标准时钟规范
•相位噪声低至150 fs at F0 = 156.25 MHz，集成的带宽12千赫- 20兆赫，LVPECL输出
•超低杂散(-113 dBc典型)
•±50 ppm过电压和温度
•支持CMOS, LVPECL, LVDS和HCSL输出
•电源电压(VIN) +2.375V ~ +3.63V
•输出启用选项;可以在引脚1或引脚2上订购
•行业标准和节省空间
5.0 mm x 3.2 mm 6针封装(MX55)和5.0 mm × 7.0 mm (MX57)
•-40°C至+85°C工作温度范围
•无铅，符合RoHS标准
•生产周期短
MX555ABB100M000RA-6G模块晶振-LVDS差分晶振参数图
1.252V Max
1.602V Max
项目
规格说明
条件
额定频率
100MHz
请联系我们以便获取其它可用频率的相关信息
电源电压
3.3V
储存温度
-55℃~+150℃
裸存
工作温度
-40℃~ +85℃
频率稳定度
±50ppm
包括初始精度，温度漂移，老化，冲击和振动
老化
±5ppm
1 year @ +25°C
电流
90mA Max
LVDS
占空比
45%~55%
Differential
输出逻辑电平低（Vol）
0.898V Min
RL = 100Ω termination from Q to Q
输出逻辑电平高（Voh）
1.248V Min
起始时间
20ms Max
From 90% VDD to valid clock output, T = +25° C
差分输出电压
454mV Max
输出上升下降时间
400ps Max
集成相位噪声
140fs Typ
12 kHz to 20 MHz @ 200 MHz，RMS
周期抖动
2.5ps
RMS
MX555ABB100M000RA-6G模块晶振-LVDS差分晶振 尺寸图
